Cworth Energy are available, with some key differences being voltage and cycle life. All use LiFePO4 chemistry and an intelligent Battery Management System (BMS
5kWh, 24V (Model: CE-LBD-24200)
Based on product listings from retailers like Zit Nigeria, the 24V model has the following specifications:
Capacity: 5kWh
Nominal Voltage: 25.6V
Maximum Charge/Discharge Current: 120A
Recommended Charge/Discharge Current: ≤60A
Maximum Output Power: 3000W
Cycle Life: ≥3200 cycles
Connectivity: Can be connected in series for 48V with two packs, or in parallel (2–6 packs)
Dimensions: 470 x 300 x 285 mm
Weight: 45kg
5kWh, 48V (Model: CE-LBT-48100C)
According to the Cworth Energy website, here are the specifications for the 48V model:
Capacity: 5kWh
Nominal Voltage: 51.2V
Maximum Charge/Discharge Current: 100A
Recommended Charge/Discharge Current: ≤60A
Maximum Output Power: 5120W
Cycle Life: ≥6000 cycles at 80% Depth of Discharge (DOD)
Communication Ports: RS485, CAN
Connectivity: Can be connected in parallel (1–6 units)
Dimensions: 490 x 440 x 185 mm
Weight: 45kg
Other features for all models
Battery Chemistry: All Cworth 5kWh batteries use lithium iron phosphate (LiFePO₄) cells, which offer reliability and a long lifespan.
Safety Features: An intelligent BMS provides protection against overcharging, over-discharging, overheating, and short-circuiting.
Compatibility: The batteries are designed for broad compatibility with most off-grid and hybrid inverters.
